Unit: Fabricating cabinets

Supporting: LMFKB3005A Fabricate cabinets for the built-in environment

Section 1: Manufactured boards


Image for slide 1
Audio for slide 1 (mp3 |6|KB)
Hardboard is made from wood fibres compressed into a sheet in a high temperature press.

In principle, the bonding is achieved entirely through the 'felting' process of the fibres and the natural glue, or lignin, already present in the wood.

However, other chemicals can be added to improve the board's strength and resistance to moisture, fire, insect attack and decay.

It is also often pre-painted on one face.

hearing icon
Image for slide 2
Audio for slide 2 (mp3 |6|KB)
Hardboard is often referred to by the trade name 'Masonite', which comes from the Mason gun used to produce the wood fibres.

In this process, the wood chips are steam heated in a high-pressure cylinder and then released into a cyclone, which causes the chips to explode into fibres.

hearing icon
Image for slide 3
Audio for slide 3 (mp3 |6|KB)

Types of Hardboards

Standard hardboard is used for wall linings, door skins, cabinet backs, drawer bases, and other interior purposes.

Underlay hardboard is treated to improve its moisture resistance, and is used under floor coverings.

Tempered hardboard is treated to give it more strength and better resistance to moisture, so it can be used as a lining where moisture may be present.

Exterior hardboard is treated to make it resistant to moisture and weathering, so it can be used for cladding and other outside applications.

hearing icon
Image for slide 4
Audio for slide 4 (mp3 |6|KB)

Advantages

Hardboard can be nailed or screwed close to the edge, and does not split, chip-out or produce splinters.

The board is also flexible and easy to bend into curved shapes.

Because of its strength and smooth surface it is ideal for cabinet backs and drawer bottoms.

It is also widely used in templates and jigs.

hearing icon
Image for slide 5
Audio for slide 5 (mp3 |6|KB)

Disadvantages

Hardboard is a high-density material and tends to blunt cutters more quickly than other board products.

It is also generally only available in thin sheets - the standard thicknesses are 3.2 mm and 4.8 mm.

hearing icon


Learning activity

Audio 6 (mp3 |6|KB)

Hardboard was once commonly used in kitchen and bathroom cabinet backs and drawer bottoms.

However, it is much less popular now and has largely been replaced by melamine-faced particleboard or MDF.

Do you use hardboard in any of your cabinets or other furniture items?

If so, where do you use it and why is it considered the best choice for that application?

Share your answers with your trainer and other learners in your group.
