Unit: Fabricating cabinets

Supporting: LMFKB3005A Fabricate cabinets for the built-in environment

Section 1: Manufactured boards

Medium density fibreboard


Image for slide 1
Audio for slide 1 (mp3 |6|KB)

Medium density fibreboard, or MDF, is manufactured in a similar way to particleboard, using the same sorts of glues and additives.

The big difference is in the way the wood fibres are treated before they're pressed.

The wood is heated under pressure until the fibres and natural glues that bond them together soften, and then the fibres are rubbed apart to produce a much finer material for pressing.

hearing icon
Image for slide 2
Audio for slide 2 (mp3 |6|KB)
The end result is a sheet with a higher density than particleboard and an even consistency right through to the centre.

This allows MDF to be machined or routered to a profile on the face and edge without the fibres pulling out or chipping.

It can also be sanded and painted to give a smooth finish.

hearing icon
Image for slide 3
Audio for slide 3 (mp3 |6|KB)

There are two types of MDF:

  • Standard MDF, which uses urea formaldehyde as the adhesive

  • Moisture resistant MDF, which uses melamine and urea formaldehyde
hearing icon
Image for slide 4
Audio for slide 4 (mp3 |6|KB)

Advantages

MDF doesn't warp or twist under normal conditions.

It can be drilled, sanded, routed and re-sawn without splintering or chipping.

Because of its consistent density, its face and edges can be machined to a profile, without the need for a separate edge strip.

hearing icon
Image for slide 5
Audio for slide 5 (mp3 |6|KB)
MDF can also be painted, stained or clear finished, and is often used for high-gloss enamel-finished items.

And it is an excellent substrate for laminates, including wood veneers, vinyls and melamine.

hearing icon
Image for slide 6
Audio for slide 6 (mp3 |6|KB)

Disadvantages

Like particleboard, MDF does not tolerate wet conditions.

Moisture-resistant boards are able to cope with areas of high humidity and occasional wetting, but they still need to be protected from prolonged contact with moisture.

MDF will also swell and shrink in response to changes in humidity.

In locations where dimensions are critical, MDF should be acclimatised for up to 48 hours prior to use to make sure that its moisture content is in balance with the surrounding atmosphere.

hearing icon


Learning activity

Audio 7 (mp3 |6|KB)

Have you heard the term 'acclimatise' before?

It's the process of bringing the board's moisture content in line with the surrounding atmosphere - or 'climate' - by letting the board naturally take up or give off moisture into the air over a period of time.

How would you do this if you had several large sheets?

That is, how would you stack the sheets to ensure that the air could circulate around all surfaces?

Write down your answer and share it with your trainer and other learners in your group.

If you have examples in your own workplace of methods used to acclimatise board products, take some digital photos to include with your answer.

hearing icon
